Still Marking Airfields the Hard Way?

When every closure window is limited, small marking errors can turn into repainting, wasted paint, and delayed reopening.

   Spending time on layout before marking starts.


   Carrying old line errors into the next repaint.


   Rushing corrections before the runway reopens.


Still Marking Airfields the Hard Way?

When every closure window is limited, small marking errors can turn into repainting, wasted paint, and delayed reopening.

   Spending time on layout before marking starts.

   Carrying old line errors into the next repaint.

   Rushing corrections before the runway reopens.

Make Every Marking Window Count

FJD PaintMaster Airfield helps crews mark faster with less manual layout work.

50%+
less manpower required

Up to 3x
faster marking workflow

30-50%
shorter runway closure time*

One Robot.

Two Airfield Marking Workflows.

New Markings

Im​port approved CAD drawings and convert them into executable robot paths for runways, taxiways, and aprons.

Existing Line Marking

Use V4E Pro to verify reference points, correct site deviations, and avoid repeating old marking errors.

Built to See, Position, and Protect

 Control Every Stage of the Marking Job

Pre-Job Route Preview

Preview the route and marking sequence before work starts, so crews can reduce on-site adjustments inside the closure window.

Real-Time Job Monitoring

Track job progress, operating time, battery level, paint status, and machine alerts while work is underway.

Local Network Deployment

Keep CAD drawings, point data, job records, and operation logs within your airport network.

Extended Operation Support

Quick-swap batteries help crews continue night and extended marking tasks with fewer interruptions from charging downtime.

From Plan to Report

A connected workflow keeps each marking job planned, checked, executed, and recorded from setup to completion.

Built for Airfield Marking Applications

  Runways
Taxiways
Aprons


 Parking & Service Areas

Ready for Your Next Airfield Marking Project

 From site verification to training and commissioning, FJD supports every step before your first marking job.


   01 Before Deployment

   CAD preparation · Local server planning

   02 On Site

    Field verification · Operator training · Commissioning

   03 After Operation

    Job report setup · Workflow review · Ongoing support

Ready for Your Next Airfield Marking Project

 From site verification to training and commissioning, FJD supports every step before your first marking job.

   01 Before Deployment

   CAD preparation · Local server planning

   02 On Site

    Field verification · Operator training · Commissioning

   03 After Operation

    Job report setup · Workflow review · Ongoing support

SPECS

Complete Unit


Weight
210 kg (463 lbs)
Dimensions
1540 x 1215 x 980 mm ( 60.6 x 47.8 x 38.6 in.)
Software Updates
OTA
Connectivity
4G, wireless connection
Water Resistance Rating
IPX4
Operating Temperature
5–35 °C

Line Marking System


Line Width Adjustment Range
10—30 cm ( 3.9-11.8 in.)
Marking Speed
1–4 km/h
Paint Tank Capacity
19 L (5 gal)
Maximum Flow Rate
2 L/min
Maximum Pressure
20 MPa

Battery & Charging


Battery Voltage
48 V
Battery Capacity
4 kWh
Runtime
6 h
Charging Time
4 h
Quick-Swap Battery
Supported
Optional / Standard /Unavailable

*Actual results may vary by task, site conditions, and operating setup.
